Abstract
The Ellesmeroceratida contains some of the oldest known fossil cephalopods. The order is almost entirely restricted to the latest Cambrian to Early Ordovician and is crucial for understanding the origin and early radiation of cephalopods. Here, we describe the new ellesmeroceratid genus Ninmarooceras from the Cambrian-Ordovician transition of the Ninmaroo Formation at Black Mountain, western Queensland, Australia. This genus is unique among cephalopods in its peculiarly shaped diaphragms that are steeply inclined and branch towards the venter. Besides the straight to very slightly endogastrically curved type species Ninmarooceras ramosum gen. et sp. nov., we describe a second species, N. exoundulatum gen. et sp. nov. The latter species is slightly older and combines an exogastrically curved conch with shallow undulations. The combined occurrence of these features within a single genus calls into question their diagnostic potential in distinguishing between taxonomic groups above genus level of the Ellesmeroceratida and related early cephalopods. The variability of diaphragm morphology also supports the restriction of the Yanheceratidae Chen and Qi, 1979 as a family within the Ellesmeroceratida instead of its own order. We further discuss evolutionary and functional implications of the unique internal siphuncle structure of Ninmarooceras.
References
Brock, G.A., Zhang, Z.-L. and Smith, P.M. 2026. A new silicified plectorthoid brachiopod from the upper Furongian (Stage 10) Ninmaroo Formation at Black Mountain, western Queensland, Australia. Palaeoworld 35: 200989. https://doi.org/10.1016/j.palwor.2025.200989
Chen, J.-Y. and Qi, D.-L. 1982. Upper Cambrian Cephalopoda from Suxian of Anhui Province. Acta Palaeontologica Sinica 21: 392–403 [in Chinese].
Chen, J.-Y. and Teichert, C. 1983. Cambrian Cephalopoda of China. Palaeontographica Abteilung A 181: 1–102.
Chen, J.-Y., Zou, X.-P., Chen, T.-E. and Qi, D.-L. 1979a. Late Cambrian cephalopods of North China. Plectronocerida, Protactinocerida (ord. nov.) and Yanhecerida (ord. nov.). Acta Palaeontologica Sinica 18: 1–24 [in Chinese].
Chen, J.-Y., Zou, X.-P., Chen, T.-E. and Qi, D.-L. 1979b. Late Cambrian Ellesmerocerida (Cephalopoda) of North China. Acta Palaeontologica Sinica 18: 103–124 [in Chinese].
Cichowolski, M., Vaccari, N., Pohle, A., Morón-Alfonso, D.A., Vaucher, R. and Waisfeld, B.G. 2023. Early Tremadocian cephalopods from Santa Rosita Formation in NW Argentina: the oldest record for South America. Acta Palaeontologica Polonica 68: 583–601. https://doi.org/10.4202/app.01103.2023
Cuvier, G. 1797. Tableau élémentaire de l’histoire naturelle des animaux [Elemental table of the natural history of animals]. Badouin, Paris. 14 pp.
Druce, E.C. 1978. Correlation of the Cambrian/Ordovician boundary in Australia. Bulletin - Bureau of Mineral Resources, Geology and Geophysics (Australia) 192: 49–60.
Druce, E.C. and Jones, P.J. 1971. Cambro-Ordovician conodonts from the Burke River Structural Belt, Queensland. Bulletin - Bureau of Mineral Resources, Geology and Geophysics (Australia) 110: 1–158.
Druce, E.C., Shergold, J.H. and Radke, B.M. 1982. A reassessment of the Cambrian-Ordovician boundary section at Black Mountain, western Queensland, Australia. In: Bassett, M.G. and Dean, W.T. (Eds.) The Cambrian-Ordovician boundary: sections, fossil distributions, and correlations. National Museum of Wales, Geological Series No. 3, Cardiff. 193–209.
Dzik, J. 2020. Variability of conch morphology in a cephalopod species from the Cambrian to Ordovician transition strata of Siberia. Acta Palaeontologica Polonica 65: 149-165. https://doi.org/10.4202/app.00674.2019
Evans, D.H. 1992. Phragmocone implosion in Ordovician nautiloids and the function of siphonal diaphragms and endocones. Palaeontology 35: 585–595.
Evans, D.H. 2005. The Lower and Middle Ordovician cephalopod faunas of England and Wales. Monograph of the Palaeontographical Society 158: 1–81.
Evans, D.H. and King, A.H. 1990. The affinities of early oncocerid nautiloids from the Lower Ordovician of Spitsbergen and Sweden. Palaeontology 33: 623–630.
Evans, D.H. and King, A.H. 2012. Resolving polyphyly within the Endocerida: The Bisonocerida nov., a new order of early Palaeozoic nautiloids. Geobios 45: 19–28. https://doi.org/10.1016/j.geobios.2011.11.015
Flower, R.H. 1941. Cephalopods from the Seward Peninsula of Alaska. Bulletins of American Paleontology 27: 1–22.
Flower, R.H. 1954. Cambrian cephalopods. New Mexico Bureau of Mining & Mineral Resources, Bulletin 40: 1–51. https://doi.org/10.58799/b-40
Flower, R.H. 1964. The nautiloid order Ellesmeroceratida (Cephalopoda). New Mexico Bureau of Mining & Mineral Resources, Memoir 12: 1–164. https://doi.org/10.58799/m-12
Flower, R.H. and Kummel, B. 1950. A classification of the Nautiloidea. Journal of Paleontology 24: 604–616.
Jones, P.J., Shergold, J.H. and Druce, E.C. 1971. Late Cambrian and early Ordovician stages in Western Queensland. Journal of the Geological Society of Australia 18: 1–32. https://doi.org/10.1080/00167617108728740
King, A.H. and Evans, D.H. 2019. High-level classification of the nautiloid cephalopods: a proposal for the revision of the Treatise Part K. Swiss Journal of Palaeontology 138: 65–85. https://doi.org/10.1007/s13358-019-00186-4
Kobayashi, T. 1934. The Cambro-Ordovician formations and faunas of South Chosen. Palaeontology. Pt. I, Middle Ordovician faunas. Journal of the Faculty of Science, University of Tokyo, Section II: Geology, Mineralogy, Geography, Seismology 3: 329–529.
Kröger, B., Beresi, M.S. and Landing, E. 2007. Early orthoceratoid cephalopods from the Argentine Precordillera (Lower-Middle Ordovician). Journal of Paleontology 81: 1266–1283. https://doi.org/10.1666/06-013.1
Kröger, B. and Evans, D.H. 2011. Review and palaeoecological analysis of the late Tremadocian - early Floian (Early Ordovician) cephalopod fauna of the Montagne Noire, France. Fossil Record 14: 5–34. https://doi.org/10.1002/mmng.201000013
Kröger, B. and Landing, E. 2007. The earliest Ordovician cephalopods of eastern Laurentia - ellesmerocerids of the Tribes Hill Formation, eastern New York. Journal of Paleontology 81: 841–857. https://doi.org/10.1666/pleo05-166.1
Kröger, B. and Landing, E. 2009. Cephalopods and paleoenvironments of the Fort Cassin Formation (upper Lower Ordovician), eastern New York and adjacent Vermont. Journal of Paleontology 83 (5): 664–693. https://doi.org/10.1666/08-181.1
Kröger, B. and Pohle, A. 2021. Early-Middle Ordovician cephalopods from Ny Friesland, Spitsbergen – a pelagic fauna with Laurentian affinities. European Journal of Taxonomy 783: 1–102. https://doi.org/10.5852/ejt.2021.783.1601
Kröger, B., Vinther, J. and Fuchs, D. 2011. Cephalopod origin and evolution: A congruent picture emerging from fossils, development and molecules: Extant cephalopods are younger than previously realised and were under major selection to become agile, shell-less predators. BioEssays 33: 602–613. https://doi.org/10.1002/bies.201100001
Landing, E. and Kröger, B. 2009. The oldest cephalopods from east Laurentia. Journal of Paleontology 83: 123–127. https://doi.org/10.1666/08-078R.1
Laurie, J.R., Kruse, P.D., Brock, G.A., Holmes, J.D., Jago, J.B., Betts, M.J., Paterson, J.R. and Smith, P.M. 2024. The quest for an Australian Cambrian stage scale. Alcheringa: An Australasian Journal of Palaeontology 48: 258–277. https://doi.org/10.1080/03115518.2024.2327045
Malinovskaya, V.D. 1964. Pozdnekembriskie nautiloidei chrebta Malyy Karatau [Late Cambrian nautiloids of the Malyy Karatau]. Paleontologicheskii Zhurnal 1: 56–62 [in Russian].
MolluscaBase eds. 2025. MolluscaBase. Ellesmeroceratida †. Accessed: 31st July 2026. https://www.molluscabase.org/aphia.php?p=taxdetails&id=1727087
Mutvei, H. and Stumbur, H. 1971. Remarks on the genus Pictetoceras (Cephalopoda: Ellesmerocerida). Bulletin of the Geological Institutions of the University of Uppsala, New Series 2: 117–122.
Mutvei, H., Zhang, Y.-B. and Dunca, E. 2007. Late Cambrian plectronocerid nautiloids and their role in cephalopod evolution. Palaeontology 50: 1327–1333. https://doi.org/10.1111/j.1475-4983.2007.00708.x
Nicoll, R.S. and Shergold, J.H. 1991. Revised Late Cambrian (pre-Payntonian-Datsonian) conodont biostratigraphy at Black Mountain, Georgina Basin, western Queensland, Australia. BMR Journal of Australian Geology & Geophysics 12: 93–118.
Peterman, D.J., Barton, C.C. and Yacobucci, M.M. 2019. The hydrostatics of Paleozoic ectocochleate cephalopods (Nautiloidea and Endoceratoidea) with implications for modes of life and early colonization of the pelagic zone. Palaeontologia Electronica 22: 24A. https://doi.org/10.26879/884
Peterman, D.J. and Ritterbush, K.A. 2022. Stability–maneuverability tradeoffs provided diverse functional opportunities to shelled cephalopods. Integrative Organismal Biology 4: obac048. https://doi.org/10.1093/iob/obac048
Pohle, A., Jell, P. and Klug, C. 2024. Plectronoceratids (Cephalopoda) from the latest Cambrian at Black Mountain, Queensland reveal complex three-dimensional siphuncle morphology, with major taxonomic implications. PeerJ 12: e17003. https://doi.org/10.7717/peerj.17003
Pohle, A., Kröger, B., Warnock, R.C.M., King, A.H., Evans, D.H., Aubrechtová, M., Cichowolski, M., Fang, X. and Klug, C. 2022. Early cephalopod evolution clarified through Bayesian phylogenetic inference. BMC Biology 20: 88. https://doi.org/10.1186/s12915-022-01284-5
Shergold, J.H. and Nicoll, R.S. 1992. Revised Cambrian–Ordovician boundary biostratigraphy, Black Mountain, western Queensland. In: Webby, B.D. and Laurie, J.R. (Eds.) Global Perspectives on Ordovician Geology. Balkema, Rotterdam. 81–92.
Shergold, J.H., Nicoll, R.S., Laurie, J.R. and Radke, B.M. 1991. The Cambrian-Ordovician boundary at Black Mountain, western Queensland: Sixth International Symposium on the Ordovician System, Guidebook for Field Excursion 1. Australian Bureau of Mineral Resources, Geology and Geophysics, Record 1991/48: 1–50.
Teichert, C. 1964. Morphology of hard parts. In: Moore, R.C. (Ed.) Treatise on Invertebrate Paleontology, Part K, Mollusca 3, Cephalopoda. Geological Society of America and University of Kansas Press, Lawrence. K13–K54.
Turner, S. 2007. Invincible but mostly invisible: Australian women’s contribution to geology and palaeontology. Geological Society, London, Special Publications 281: 165–202. https://doi.org/10.1144/SP281.11
Ulrich, E.O. and Foerste, A.F. 1936. New genera of Ozarkian and Canadian cephalopods. Denison University Bulletin, Journal of the Scientific Laboratories 30: 259–290.
Ulrich, E.O., Foerste, A.F., Miller, A.K. and Unklesbay, A.G. 1944. Ozarkian and Canadian cephalopods: Part III: Longicones and summary. Geological Society of America Special Papers 58: 1–226. https://doi.org/https://doi.org/10.1130/SPE58
Wade, M. 1988. Nautiloids and their descendants: cephalopod classification in 1986. New Mexico Bureau of Mining & Mineral Resources, Memoir 44: 15–25. https://doi.org/10.58799/m-44
Wade, M. and Stait, B. 1998. Subclass Nautiloidea - Introduction and fossil record. In: Beesley, P.L., Ross, G.J.B. and Wells, A. (Eds) Mollusca: The Southern Synthesis. Australian Biological Resources Study, Canberra. 485–493.
Webby, B.D., Vandenberg, A.H.M., Cooper, R.A., Stewart, I., Shergold, J.H., Nicoll, R.S., Burrett, C.F., Stait, B., Cooper, B.J., Laurie, J. and Sherwin, L. 1991. Subdivisions of the Ordovician System in Australia. Geological Survey of Canada, Paper 90: 47–57. https://doi.org/10.4095/132176
Zhen, Y.Y., Percival, I.G. and Webby, B.D. 2017. Discovery of Iapetognathus fauna from far western New South Wales: towards a more precisely defined Cambrian–Ordovician boundary in Australia. Australian Journal of Earth Sciences 64: 487–496. https://doi.org/10.1080/08120099.2017.1321043
Zhen, Y.Y., Percival, I.G., Smith, P.M. and Webby, B.D. 2025. Latest Cambrian–earliest Ordovician conodonts from far western New South Wales and their biostratigraphical significance. Alcheringa: An Australasian Journal of Palaeontology 49: 499–547. https://doi.org/10.1080/03115518.2025.2463062
